BETA STAR 3" × 3" DIESEL FIRE PUMP

Cast Iron High-Performance Water Transfer System with 186FA Engine

When serious water movement is required, the Beta Star 3" Cast Iron Fire Pump delivers industrial-grade performance. Powered by the powerful 186FA diesel engine, this heavy-duty pump is engineered for firefighting support, agricultural irrigation, construction dewatering, and large-volume emergency water transfer operations.

Built with a reinforced cast iron volute housing and mounted inside a protective steel roll cage frame, this unit is designed to operate in demanding agricultural, municipal, and industrial environments where durability and output matter.

ENGINE PERFORMANCE

Engine Model: 186FA Diesel Engine
Power Output: 5.7 kW / 6.3 kW
Operating Speed: 3000 / 3600 RPM
Bore × Stroke: 86 × 72 mm
Cooling System: Heavy-duty air-cooled
Starting System: Electric start with battery + recoil backup
Net Weight: 48 kg

Designed for high torque output, stable RPM control, fuel-efficient operation, and consistent water pressure under load.

PUMP SPECIFICATIONS

Suction / Discharge Port: 3" × 3" (80 mm)
Maximum Capacity: 42 m³/h
Maximum Head: 40 metres
Maximum Suction Head: 7 metres
Pump Material: Heavy-duty Cast Iron
Model: KDP30DEP208

Engineered for high-volume discharge and sustained operational performance.

CONSTRUCTION QUALITY

✔ Industrial cast iron impeller housing
✔ Powder-coated corrosion-resistant steel frame
✔ Reinforced vibration-dampening base
✔ Heavy-duty steel protective roll cage
✔ Electric start battery system included
✔ Industrial mechanical seal assembly

Built for farms, estates, construction sites, flood response operations, and firefighting backup systems.

APPLICATIONS

Firefighting support systems
Large-scale agricultural irrigation
Construction site water removal
Flood drainage & emergency pumping
Industrial water transfer

This is a serious diesel-powered pump — not a lightweight domestic water mover.
